Looking for a reliable 316 stainless steel foil supplier?
Huaxiao Metal provides ultra thin 316 / 316L stainless steel foil with high precision thickness control, excellent corrosion resistance, and superior surface quality. Our foil products are widely used in electronics, lithium batteries, medical devices, and the chemical industries.
With advanced production lines and strict quality control, we ensure consistent performance for high-end applications.
👉 Contact us today to get a fast quotation within 12 hours.
Contents [hide]
China 316 Stainless Steel Foil Manufacturers | Suppliers | Exporters
As a leading 316 stainless steel foil supplier, we offer ultra-thin, high-performance metal foils designed for industries that require superior corrosion resistance, durability, and thermal stability. Available in custom thicknesses (0.005 mm to 0.3 mm) and widths, our stainless steel foils are ideal for aerospace, medical devices, chemical processing, and marine environments.
Contact us today to request a quote or learn more about our 316 stainless steel foil products.
Range of Precision 316 Stainless Steel Foils
| Product Name | Stainless Steel Foils Roll |
|---|---|
| Thickness: | 0.005-0.3mm, etc. |
| Length: | Customizable |
| Width: | Customizable |
| Standard: | ASTM A167,ASTM A176,ASTM A240,ASTM A262,ASTM A666,ASTM A693,ASTM A763….. |
| Surface: | BA，2B， NO.4， HL，8K, etc. |
| Certification: | ISO, SGS， BV, etc. |
| Technique: | Cold Rolled |
| Grade: | 316 |
Custom sizes and precision slitting available.
316 Stainless Foil Thickness Guide
The thickness of 316 stainless steel foil is a key factor affecting performance and price.
📏 Common Thickness Range:
0.01 mm – ultra thin precision applications
0.02 – 0.05 mm – electronics & battery components
0.05 – 0.1 mm – industrial use
0.1 – 0.2 mm – general applications
316 Stainless Steel Foil Data Sheet
316 Stainless Steel Foil Chemical Composition
The chemical components of grade 316 stainless steel foil roll are summarized in the following table:
| Element | Cr | Ni | C | Mn | Si | P | S | Mo |
|---|---|---|---|---|---|---|---|---|
| Composition Range (% by weight) | 16% – 18% | 10% – 14% | 0.08% max | 2.0% max | 0.75% max | 0.045% max | 0.03% max | 2% – 3% |
This table outlines the typical ranges of the major alloying elements in 316 stainless foil. Please note that these percentages may vary slightly depending on the specific manufacturing standards or requirements of a particular product or supplier.
316 Stainless Steel Foil Mechanical Properties
The mechanical properties of grade 316 foil are summarized in the following table:
Mechanical Properties | Tensile Strength | Yield Strength | Elongation | Hardness |
|---|---|---|---|---|
| Typical Value | 75,000 – 85,000 psi | 30,000 – 35,000 psi | 40% min | Around 95 HRB or less |
These mechanical property parameters describe how 316 stainless steel foil behaves when subjected to stress. Yield strength is the point at which a material begins to deform, while tensile strength indicates the maximum tensile load a material can withstand. Elongation indicates how much a material can stretch when stretched. Hardness indicates the material’s resistance to scratches and pressure.
Please note that the mechanical property parameters of specific products may vary depending on manufacturing standards, processing conditions, and suppliers.
316 Stainless Steel Foil Physical Properties
| Property | Value |
|---|---|
| Density | 7.98 g/cm³ |
| Melting Point | 1,370°C – 1,390°C |
| Thermal Conductivity | 16.3 W/(m·K) |
| Coefficient of Linear Expansion | 16.5 x 10^-6/°C |
| Electrical Conductivity | 1.25 x 10^6 S/m |
| Modulus of Elasticity | 193 – 200 GPa |
These physical property parameters describe the behavior of 316 stainless foil under various physical conditions. Density is the ratio of a substance’s mass to its volume, usually expressed in grams per cubic centimeter (g/cm³). The melting point is the temperature at which a material changes from a solid to a liquid state. Thermal conductivity represents a material’s ability to conduct heat, while the coefficient of linear expansion describes the dimensional changes in a material as temperature changes. Conductivity measures a material’s ability to conduct electricity.
Please note that these values are typical physical property parameters of 316 stainless steel and actual values may vary depending on manufacturing standards, processing conditions, and specific alloy composition.
Contact Us For The China 316 Stainless Steel Foil Price!
Application of China 316 Stainless Steel Foil
Chemical Industry: Used in the manufacture of corrosion-resistant chemical equipment and pipelines, 316 ss foil exhibits excellent resistance to a variety of corrosive chemicals.
Food Processing: Widely used in food processing equipment such as food grade containers, conveyor belts, and machinery due to its hygienic properties and corrosion resistance.
Medical Devices: Used in the manufacture of medical instruments and equipment because it is corrosion-resistant and biocompatible, making it suitable for surgical instruments and implants.
Construction: Used in architectural features such as decorative panels, roofs, and decorative elements to provide durability against environmental factors.
Electronics Industry: used in the manufacture of electronic components and connectors requiring corrosion resistance and conductivity.
Automotive Industry: used in high-temperature and corrosive environments, such as exhaust systems, catalytic converters, and other automotive parts.
Aerospace: Applied in ultra-thin structural and functional components.
Lithium Battery: Applied in battery connectors and conductive components due to excellent stability.
These are one of the main application areas of 316 stainless steel foil in China. The superior properties of this material make it the material of choice in industries that require corrosion resistance and durability. The specific application will determine the required foil thickness and other characteristics.
How To Make 316 Stainless Steel Foils?
Manufacturing 316 stainless steel foils involves a series of processes to transform stainless steel into thin, flat sheets or strips. Here’s a general overview of how 316 stainless steel foils are made:
- Raw Materials: The process begins with the selection of high-quality stainless steel alloy, typically Type 316, which contains specific amounts of chromium, nickel, molybdenum, and other elements.
- Melting: The chosen stainless steel alloy is melted in an electric arc furnace or an induction furnace. During this process, various alloying elements may be added to achieve the desired composition.
- Casting: The molten stainless steel is cast into thick slabs or billets. These slabs are then hot-rolled to reduce their thickness.
- Hot Rolling: The slabs are heated and passed through a series of rolling mills to reduce their thickness further. This hot-rolling process can be repeated several times until the desired thickness is achieved.
- Cold Rolling: After hot rolling, the stainless steel strips go through a cold rolling process. Cold rolling involves passing the material through rollers at room temperature to further reduce its thickness and improve surface finish. This process may also involve annealing (heat treatment) to enhance the material’s properties.
- Annealing: Stainless steel foils are often subjected to an annealing process to relieve stress, improve ductility, and enhance their mechanical properties. Annealing involves heating the material to a specific temperature and then slowly cooling it.
- Trimming and Slitting: The stainless steel strip is trimmed to the desired width, and then it can be slit into narrower foils if needed.
- Surface Treatment: Surface treatments such as pickling, passivation, or polishing may be applied to improve the appearance and corrosion resistance of the stainless steel foils.
- Quality Control: The finished foils undergo stringent quality control checks to ensure they meet the required thickness, mechanical properties, and surface finish specifications.
- Coiling and Packaging: The stainless steel foils are coiled and packaged according to customer specifications for transportation and storage.
It’s important to note that the specific manufacturing processes and equipment used can vary between manufacturers and regions. Quality control and adherence to industry standards are essential throughout the production process to ensure the consistent quality of 316 stainless steel foils.
Contact Us For The China 316 Stainless Steel Foil Price!
Package of China 316 Stainless Steel Foil Rolls
We usually use conventional export packaging standards and then put about 10 packs of desiccant in the container.
If customers have other packaging requirements, we can also adjust the packaging according to customer requirements.
316 Stainless Steel Foil Price
The price of 316 stainless steel foil depends on thickness, precision, and order quantity.
💰 Reference Price:
$4 – $8 per kg (varies by thickness and specs)
Thin and high-precision foil usually has a higher cost due to complex processing.
👉 Contact us now for the latest price.
Custom Stainless Steel Foil Solutions
Huaxiao Metal offers customized solutions based on your requirements:
Custom thickness and width
Precision slitting services
Hardness control
Surface finishing options
👉 Send your drawings or specifications today.
Quality Control Standards at Huaxiao Metal
Thickness Uniformity: Real-time AGC (Automatic Gauge Control) during rolling to ensure sub-micron precision.
Surface Quality: 100% visual inspection for scratches, pinholes, or oil stains.
Chemical Analysis: Every batch is tested by Spectrometer to ensure Ni (10-14%) and Mo (2-3%) content.
Custom Packaging: Vacuum packaging or moisture-proof paper to prevent oxidation during sea freight.
Why Choose Huaxiao Metal?
Factory direct price
Advanced precision production lines
Stable quality with strict inspection
Fast delivery worldwide
Rich export experience
👉 Get your custom foil quote now.
FAQ – 316 Stainless Steel Foil
What is the difference between 316 stainless steel foil and 316L stainless steel foil?
316L is a low-carbon version of 316 (L stands for Low Carbon). 316 stainless steel foil has a maximum carbon content of 0.08%, while 316L stainless steel foil has a maximum carbon content of 0.03%. In welding applications, 316L effectively prevents intergranular corrosion, making it a better choice for welding applications. Huaxiao Metal manufactures and offers both grades in stock.
How do you guarantee the quality of your 316 stainless steel foil as a manufacturer?
As a professional 316 stainless steel foil manufacturer, we implement a rigorous five-step quality inspection process: raw material spectral analysis, online thickness measurement during cold rolling, surface inspection after bright annealing, finished product mechanical property testing, and final inspection before shipment. All products come with an MTC report to ensure compliance with customer specifications and international standards.
How are your 316 stainless steel foil prices calculated? Do you have stock available?
316 stainless steel foil prices are primarily based on thickness, width, order quantity, and the market price of raw materials (nickel, molybdenum). We offer transparent factory-direct pricing. Huaxiao Metal maintains a large inventory of various specifications in stock to meet small batch and urgent order needs. Please contact us for a real-time inquiry based on the current market and your requirements.
Can I customize the thickness and width of my 316 stainless steel foil?
Yes, Huaxiao Metal specializes in precision stainless steel manufacturing. We offer custom thicknesses from 0.005mm to 0.3mm, as well as custom width services with high-precision slitting according to customer requirements. Our factory’s flexible production lines can meet the requirements of non-standard products.
Is 316 foil suitable for medical use?
Yes, due to excellent corrosion resistance and biocompatibility.
